USB 3.0 Interface And 16bit Dynamic Range FW-A5 Cooled Infrared Detector For Infrared Thermal Imaging Products
| Place of Origin | China |
|---|---|
| Brand Name | Forward |
| Model Number | FW-A5 |
| Minimum Order Quantity | 1 set |
| Delivery Time | 5-8 work days |
| Payment Terms | L/C, T/T |
| Supply Ability | 100 pcs/year |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Refrigeration Method | Stirling Refrigerator, Liquid Nitrogen Refrigeration,TEC | Refrigeration Temperature | 77k(liquid Nitrogen Refrigeration),80K-150K(Stirling Refrigerator) |
|---|---|---|---|
| Dynamic Range | 14-bit,16bit | Interface | Camera Link,GigE Vision,USB 3.0 |
| Highlight | USB 3.0 Interface Infrared Detector,16bit Dynamic Range Infrared Detector,FW-A5 Cooled Infrared Detector |
||
Product Description
Descriptions of FW-A5 Cooled infrared detector
The cooled infrared detector is a highly sensitive and high-resolution infrared imaging device, which is widely used in military, aerospace, industrial detection, medical diagnosis and other fields. The detector uses cooling technology to reduce noise and improve detection sensitivity, and can capture clear infrared images under extremely low light conditions.
Features of FW-A5 Cooled infrared detector
- High sensitivity, suitable for low light environment
-
High resolution for clear image details
-
Low noise, improved detection accuracy
-
Multiple interfaces for easy system integration
-
Rugged and durable, suitable for harsh environments
Specifications of FW-A5 Cooled infrared detector
| Pixel size | 15µm x 15 µm,20µm x 20µm |
| NETD | <20 mK @ 25°C |
| Frame rate | 30 Hz,60Hz,100Hz |
| Working band | 3-5 µm,8-12µm |
|
Operating temperature |
-40℃ ~ +60℃
|
| Weight | 1-2 kg |
| Power consumption | 5-10 W |
| Supply voltage | 12 V DC/24 V DC |
| Resolution | 320x256,640x512,1024x768 |
Applications of FW-A5 Cooled infrared detector
- Military: night vision, target tracking, missile guidance
- Security: border monitoring, night patrol
- Industry: equipment fault detection, thermal imaging analysis
- Scientific research: astronomical observation, environmental monitoring
